Steel wire screw sleeve vision inspection machine

Steel wire screw sleeve visual screening machine, this machine uses a vibrating disc for feeding, is equipped with 360 ° artificial intelligence visual inspection software, and is equipped with 5 CCD industrial cameras. According to customer requirements, it can detect whether key dimensions such as color difference, outer diameter, size, etc. of the product meet the drawing requirements, as well as whether there are appearance defects such as tooth leakage and slag blockage on the surface of the product. The detection speed is 500pcs/min, and the detection accuracy is ± 0.01mm

Video Player

Media error: Format(s) not supported or source(s) not found

Download File: https://www.rkeinspection.com/wp-content/uploads/2024/09/8%E6%9C%886%E6%97%A53C%E6%A8%AA%E5%B1%8F-E.mp4?_=1

00:00

Use Up/Down Arrow keys to increase or decrease volume.

Thank you for your trust in RKE Intelligent Technology Co., Ltd. We will provide you as following:

Item

Product

Specification

Optical Sorting machine-RK1900-C7

1. Inspection Component: size / appearance defective
2. Camera : Hi-Vison Color CCD (200w)
3. Light Source: RGB cascade multi-angle LED combination lighting, high brightness, 2M pixels tele-centric lens, 50*50mm
4. Motor：Japan Panasonic
5. Computer: Dell 2.7G, DDR II 2.0G, 500G , 19″ wide screen LCD
6. Software: RKE self-developed（based on labview）
7. Solenoid valve: American Newmandick solenoid valve
8. Power: 220V/50Hz ,1000W
9. Accuracy : ± 0.01mm
10. Detect Speed : 500pcs/min

11.Machine size: 1500*1300*1860(2150)mm,Weight: 355KGS

12. Vibrating Device size: 650*800*1350mm, Weight: 255kgs
